10ft Wallbox

SKU WB-10

Ships in: 1 carton
Weight: 8–45 lbs

Specifications

Typed values from the master record. Last verified Aug 11, 2026.

Product code	WB-10
Shipping cartons	68″ W × 19″ H × 12″ D · 10ft Hardware Only
Shipping weight	10ft Hardware Only 31 lbs 10ft Single Sided Graphic Package with Black Back Fabric 45 lbs 10ft Single Sided Graphic Package with Black Back Fabric 39 lbs 10ft Single Sided Graphic Package with White Back Fabric 39 lbs 10ft Single Sided Graphic Only with Black Back Fabric 8 lbs 10ft Single Sided Graphic Only with Black Back Fabric 8.71 lbs 10ft Single Sided Graphic Only with White Back Fabric 8 lbs 10ft Single Sided Graphic Only with White Back Fabric 14.51 lbs 10ft Double Sided Graphic Only 12.51 lbs 10ft Double Sided Graphic Only 14.51 lbs 10ft Double Sided Graphic Package 39 lbs Weight varies by configuration — you receive the option you select.

Downloads

Installation guide (PDF)

10ft Wallbox — Installation guide

Overview

Re-introducing the new Wallbox Fabric Display, a portable unlike anything you’ve ever seen. Your exhibitors will be in awe of it’s mighty size! You might need a friend to help you set it up, but don’t let this giant dissuade you it’s completely toolless! Using the same framework as our line of Skybox Hanging Banners, set up is a snap! With push button snap locks, the tubes connect together without the need for tools. Custom dye sublimated fabric graphics fully wrap the entire frame. We offer two graphic options for the wallbox. Double sided graphic option includes dye sub printed front panel, back panel, and end caps, with plain black fabric on the top and bottom. Single sided graphic option includes dye sub printed front panel and end caps with your choice of blank white or black fabric for the backside, top, and bottom. The graphic is finished pillowcase style with a zipper at the top for easy installation and a clean finished look. A travel bag is included to transport and store your display in between events.

*Tube frame hardware is custom-made at our PFC facility, so hardware-only orders will not be available for same-day shipping.

10ft x 8ft

Graphic Packages Include

(4) 48” Tube w/2 Connectors
(4) 48” Tube w/1 Connector
(4) 36” Tube w/1 Connector
(4) 36” Tube
(1) Vertical Support Tube - Top
(1) Vertical Support Tube - Bottom
(6) Union Tubes
(2) Union Tube w/Hole
(8) Curved Corner Tubes
(1) Travel Bag
(1) Single or Double Sided Graphic

Hardware Onlys Include

(4) 48” Tube w/2 Connectors
(4) 48” Tube w/1 Connector
(4) 36” Tube w/1 Connector
(4) 36” Tube
(1) Vertical Support Tube - Top
(1) Vertical Support Tube - Bottom
(6) Union Tubes
(2) Union Tube w/Hole
(8) Curved Corner Tubes
(1) Travel Bag

Graphic Onlys Include

(1) Single or Double Sided Graphic

10ft x 8ft Features

Display Dimensions: 120”W x 96”H x 18”D
Template Dimensions Single Sided: 156“W x 96.5“H
Template Dimensions Double Sided: 138“W x 48.25“H

Shipping Weight

39 lbs (Graphic Package)
31 lbs (Hardware Only)
8 lbs (Graphic Only)

Shipping Dimensions

68” L x 19” W x 12” H (Graphic Package)
68” L x 19” W x 12” H (Hardware Only)
Poly Bag (Graphic Only)
Printing Process: Paper Transfer Dye Sublimation

Misc

Includes travel bag
Pillowcase style graphics
Single or double sided graphic display
10ft x 10ft
